View and Download Anritsu Site Master S332D user manual online. Cable and Antenna Analyzer. Site Master S332D Measuring Instruments pdf manual download. Also for: Site master s331d. The Site Master is designed for measuring SWR, return loss, or cable insertion loss and locating faulty RF components in antenna systems. Power monitoring is available as an op- tion. Site Master models S114C and S332C include spectrum analysis capability. The displayed trace can be scaled or enhanced with frequency markers or limit lines.
Technical Data Sheet
Site Master
™
Compact Handheld Cable & Antenna Analyzer
with Spectrum Analyzer
Introduction
Anritsu introduces its eighth generation compact handheld Cable and Antenna Analyzers with Spectrum Analyzers for
installation and maintenance of wireless networks. They feature the highest performance and the most capabilities ever
offered by Anritsu in a compact handheld tester since introducing its first line sweeper in 1995.
Cable and Antenna Analyzer Highlights
Measurements: RL, VSWR, Cable Loss, DTF, Phase
•
2-port Transmission Measurement: High/Low Power
•
Sweep Speed: 1 msec/data point, typical
•
Display: Single or Dual Measurement Touchscreen
•
Calibration: OSL, InstaCal
•
™
, and FlexCal
™
Bias Tee: 32 V internal
•
Spectrum and Interference Analyzer Highlights
Measurements: Occupied Bandwidth, Channel Power, ACPR, C/I
•
Interference Analyzer: Spectrogram, Signal Strength, RSSI, Signal ID,
•
Interference Mapping
Dynamic Range: > 95 dB in 10 Hz RBW
•
DANL: -152 dBm in 10 Hz RBW
•
Phase Noise: -100 dBc/Hz max @ 10 kHz offset at 1 GHz
•
Frequency Accuracy: < ± 50 ppb with GPS On
•
4 hour battery operation time
•
Store 2000 Traces internally
•
Touchscreen keyboard
•
Quick Name Matrix
•
PIM Analyzer
•
AM / FM / PM Analyzer
•
Anritsu Site Master S332e Manual
High Accuracy Power Meter
•
4, 6, 8, 18, 26 GHz USB Sensors
•
On-Screen Interference Mapping
•
On-Screen Coverage Mapping
•
GPS tagging of saved traces
•
USB & Optional Ethernet
•
(Option 0411) for data transfer
and instrument control
Increase throughput by
Anritsu Site Master
•
automating repetitive or operator
intensive tasks via Ethernet or
USB. Remote programming
provided via Ethernet (Option
0411)
< 5 minute warm-up time
•
E-Learning Training
•
Certified Line Sweep Training
•
Line Sweep Tools
•
Capabilities and Functional Highlights
S331E
S332E
S361E
S362E
2 MHz to 4 GHz
2 MHz to 4 GHz
2 MHz to 6 GHz
2 MHz to 6 GHz
Cable & Antenna Analyzer
100 kHz to 4 GHz
100 kHz to 6 GHz
Spectrum Analyzer
Site Master
™
S331E Cable & Antenna Analyzer featuring 8.4” Daylight Viewable Touchscreen
Compact Size: 273 mm x 199 mm x 91 mm (10.7 in x 7.8 in x 3.6 in), Lightweight: 2.71 kg (6.0 lbs)
